2 Pack TCL Solar TOPCon 440W Black Solar Panels – 880W Bundle

2 Pack TCL Solar TOPCon 440W Black Solar Panels – 880W Bundle

Bundle includes: 2 × TCL Solar TOPCon 440W Solar Panel Black. Each panel is rated at 440W, giving 880W total rated array capacity.

This bundle uses the exact live source panel model and technology.

What's Included

• 2 × TCL Solar TOPCon 440W Solar Panel Black

Not Included

Mounting hardware, controllers, inverters, batteries, fuses, cables and accessories are not included unless specifically stated.

Array Design Note

Electrical specifications below are per panel. Series wiring increases voltage and parallel wiring increases current. Confirm full-array electrical limits before installation.

Per-Panel Specifications & Product Details

Upgrade your solar system with the TCL TC-440-48-BLK-GG-RES, a high-performance 440W N-Type TOPCon bifacial solar panel designed for residential rooftops and commercial projects. With its sleek full black glass-glass design, this module combines powerful energy generation with premium aesthetics for seamless integration on modern rooftops.

Key Features

High Power Output: Up to 440W maximum power with N-Type TOPCon cell technology.

Superior Efficiency: Module efficiency up to 22.5%, delivering more energy from limited roof space.

Bifacial Technology: Captures sunlight on both sides for additional rear-side power gain, boosting overall yield.

Durable Glass-Glass Construction: Heat-strengthened front & back glass improves resistance to harsh environments, UV degradation, and microcracks.

Sleek Full Black Design: Enhances rooftop aesthetics with a uniform look.

Long-Term Reliability: Backed by 25 years product warranty and 30 years linear performance warranty.

Electrical Specifications (STC)*

Maximum Power (Pmax): 440W

Module Efficiency: Up to 22.5%

Open Circuit Voltage (Voc): ~49V

Short Circuit Current (Isc): ~11.5A

Maximum Power Voltage (Vmp): ~41V

Maximum Power Current (Imp): ~10.7A

Bifacial Gain: Up to 25% additional yield depending on installation

*Values based on Standard Test Conditions (STC: 1000W/m² irradiance, 25°C cell temperature, AM1.5 spectrum).

Mechanical Specifications

Dimensions: ~1722 × 1134 × 30 mm

Weight: ~22 kg

Cell Type: 210mm N-Type TOPCon, Half-Cut, 48 cells

Front Glass: 2.0 mm heat-strengthened, AR-coated

Back Glass: 2.0 mm heat-strengthened

Frame: Anodized aluminium alloy (black)

Junction Box: IP68, 3 bypass diodes

Cables & Connectors: Staubli MC4 compatible, 4mm² cables

Maximum Static Load: 5400 Pa (front), 2400 Pa (back)

Fire Rating: IEC Class C

Warranty

25-Year Product Warranty

30-Year Linear Performance Warranty (guaranteed output ≥87.4% at year 30)
