4 Pack TCL T Class 700W–725W N-Type TOPCon Bifacial Dual-Glass Solar Panels – 2800W–2900W Bundle
4 Pack TCL T Class 700W–725W N-Type TOPCon Bifacial Dual-Glass Solar Panels – 2800W–2900W Bundle
Couldn't load pickup availability
4 Pack TCL T Class 700W–725W N-Type TOPCon Bifacial Dual-Glass Solar Panels – 2800W–2900W Bundle
Bundle includes: 4 × matching TCL Solar T Class HSM-ND66-GK panels in your selected wattage. Select 700W, 705W, 710W, 715W, 720W or 725W per panel.
Combined Array Wattage
| Panel Variant | Model | 4-Panel Total |
|---|---|---|
| 700W | HSM-ND66-GK700 | 2800W |
| 705W | HSM-ND66-GK705 | 2820W |
| 710W | HSM-ND66-GK710 | 2840W |
| 715W | HSM-ND66-GK715 | 2860W |
| 720W | HSM-ND66-GK720 | 2880W |
| 725W | HSM-ND66-GK725 | 2900W |
What's Included
4 × TCL T Class panels of the selected matching wattage. Mixed wattages are not included in one bundle selection.
Not Included
Mounting rails, inverters, controllers, cables, isolators and other balance-of-system components are not included unless specifically stated.
Array Design Note
Electrical specifications below are per panel. This is a high-voltage commercial/large-format module range. Confirm string voltage/current, inverter/MPPT limits, structural loading and applicable Australian installation requirements.
Per-Panel Specifications & Product Details
TCL Solar T Class 700W–725W N-Type TOPCon Bifacial Dual-Glass Solar Panel
Built for high-output commercial and large-scale solar installations, the TCL Solar T Class HSM-ND66-GK series combines N-Type TOPCon cells, bifacial energy generation and framed glass-glass construction in outputs from 700W to 725W. The range reaches up to 23.3% module efficiency.
Electrical specifications by model
| Model | Power | Efficiency | Vmp | Imp | Voc | Isc |
|---|---|---|---|---|---|---|
| HSM-ND66-GK700 | 700W | 22.5% | 40.31V | 17.37A | 48.26V | 18.40A |
| HSM-ND66-GK705 | 705W | 22.5% | 40.50V | 17.41A | 48.48V | 18.44A |
| HSM-ND66-GK710 | 710W | 22.9% | 40.69V | 17.45A | 48.70V | 18.48A |
| HSM-ND66-GK715 | 715W | 23.0% | 40.89V | 17.49A | 48.92V | 18.52A |
| HSM-ND66-GK720 | 720W | 23.2% | 41.08V | 17.53A | 49.14V | 18.56A |
| HSM-ND66-GK725 | 725W | 23.3% | 41.27V | 17.57A | 49.36V | 18.60A |
Mechanical & system specifications
- Cell Technology: N-Type TOPCon
- Construction: Framed bifacial glass-glass
- Dimensions: 2384 × 1303 × 33mm
- Weight: 38.2kg
- Glass: 2.0mm + 2.0mm heat-strengthened glass
- Junction Box: IP68, 3 bypass diodes
- Connector: Stäubli MC4-EVO2A
- Maximum System Voltage: 1500V IEC
- Maximum Series Fuse: 35A
- Operating Temperature: -40°C to +70°C
- Power Temperature Coefficient: -0.28%/°C
- Wind Load: 2400Pa front & rear
- Snow Load: 5400Pa front
- Impact Resistance: 25mm hail at 23m/s
- Standards: IEC 61215, IEC 61730
- Fire Rating: Class A
Warranty
15-year product coverage and 30-year power coverage, subject to manufacturer warranty terms.
Important installation note
Large-format high-voltage module intended primarily for commercial, industrial and power-plant style installations. It is not a nominal 12V battery panel.
