450W 12V Mono Shingled Fixed Solar Panel
450W 12V Mono Shingled Fixed Solar Panel
Couldn't load pickup availability
450W 12V Mono Shingled Fixed Solar Panel
This 450W 12V monocrystalline shingled fixed solar panel is designed for compatible caravan, motorhome, 4WD, camper trailer, marine, tiny-home and off-grid installations. Its compact 1150 × 880 × 30mm format and listed 10kg weight can suit systems where mounting area and installed mass are important.
Use the panel with a correctly sized solar charge controller, DC-DC charger with solar input or compatible inverter. Confirm the equipment accepts the panel’s full voltage and current before ordering.
Multi-panel options: choose the 2-panel 900W bundle or 4-panel 1800W bundle. Eligible orders over $300.01 can use SPAST15 for 15% off.
Available delivery and payment options are shown at checkout.
Key features and benefits
- 450W rated peak output under standard test conditions
- Shingled monocrystalline cell technology
- Corrosion-resistant anodised aluminium frame
- High-transparency tempered-glass front cover
- Compact fixed-frame construction
- Suitable for compatible lithium, AGM and deep-cycle battery systems
- 25-year power-output warranty
Technical specifications
| Maximum power (Pmax) | 450W |
| Maximum power voltage (Vmp) | 18.5V |
| Maximum power current (Imp) | 23.6A |
| Open-circuit voltage (Voc) | 22.4V |
| Short-circuit current (Isc) | 25.1A |
| Nominal system class | 12V battery charging with suitable regulation |
| Dimensions | 1150 × 880 × 30mm |
| Weight | 10kg |
| Cell type | Monocrystalline shingled cells |
| Frame material | Heavy-duty anodised aluminium |
| Front cover | High-transparency tempered glass |
| Operating temperature | -20°C to +60°C |
| Listed protection | IP65 |
| Warranty | 25-year power-output warranty |
Recommended applications
- Caravan and RV solar systems
- 4WD and camping setups
- Marine and boating applications
- Tiny homes, cabins and sheds
- Off-grid backup and battery-charging systems
Controller, wiring and battery compatibility
Confirm the controller’s PV voltage, input-current and battery-charging limits before connection. For multiple panels, series wiring increases voltage and parallel wiring increases current. Calculate the complete array and use correctly rated cable, connectors, fuses and isolation.
Browse compatible MPPT controllers, lithium batteries, AGM batteries and aluminium Z brackets.
What’s included
- 1 × 450W 12V mono shingled fixed solar panel
Mounting hardware, controller, battery, extension cabling, fuses and isolators are not included unless stated.
Installation and output
Measure the installation area and confirm structural support before ordering. Actual output varies with sunlight, temperature, shade, mounting angle, cleanliness, cabling and controller efficiency.
For compatibility help call (02) 5761 0297.
