Gentrax 12V 100Ah Slim LiFePO4 Battery

Gentrax 12V 100Ah Slim LiFePO4 battery

The Gentrax 12.8V 100Ah Slim battery provides 1,280Wh of nominal energy in a narrow 110mm-wide case weighing approximately 9.5kg. It suits compatible caravan, 4WD canopy, RV and off-grid installations where floor space is limited.

Key benefits

• 100Ah capacity and 1,280Wh nominal energy
• 110mm-wide slimline case
• 100A rated continuous discharge and 200A maximum discharge for up to five seconds
• Approximately 3,000 cycles under the stated test conditions
• Up to four matching batteries may be connected in parallel; series connection is not supported
• Two-year warranty

Specifications

Installation and system matching

Measure the mounting area and allow room for secure restraint, cable bends and terminal access. Before replacing an AGM battery, confirm that every charging source and protection device is suitable for LiFePO4.

Compare compatible MPPT solar controllers and DC–DC chargers. When choosing a power inverter, keep continuous battery current within the 100A rating and allow for start-up surge and conversion losses.

Browse more slimline lithium batteries, all LiFePO4 batteries or the wider deep-cycle battery range.

Package contents

• 1 × Gentrax 12V 100Ah Slim LiFePO4 battery

Frequently asked questions

How wide is the battery?
The case is 110mm wide, with overall dimensions of 395 × 110 × 286mm.

Can it replace an AGM battery directly?
It may physically fit some installations, but the charger, solar controller, DC–DC charger, cabling and protection must be verified for LiFePO4 compatibility.

Can it charge below 0°C?
No. The published charging range starts at 0°C.
