Giantz Lithium Iron Battery 200AH 12V LiFePO4 Deep Cycle Battery 4WD Camping

Giantz 12.8V 200Ah LiFePO4 deep-cycle battery with approximately 2,560Wh nominal energy, integrated BMS protection and a maximum listed charge current of 100A. It is intended for appropriately designed 4WD, camping, caravan and off-grid systems.

Key Specifications

• Nominal voltage: 12.8V
• Nominal capacity: 200Ah
• Approximate nominal energy: 2,560Wh
• Maximum charge current: 100A
• Rated charge current: 50A
• Rated charger voltage: 13.6–13.8V
• Short-circuit current: approximately 1,200A
• Listed cycle life: up to 5,000 cycles at 30% depth of discharge
• Discharge temperature: -20°C to 60°C
• Charge temperature: 0°C to 45°C
• Storage temperature: -5°C to 35°C
• Overall dimensions: 50 × 24 × 22cm
• Approximate weight: 22.2kg
• Container material: ABS
• Terminals: bolt-down
• Warranty: 2 years

Important Inverter Compatibility Note

The supplied specifications list an approximate short-circuit current but do not state a maximum continuous-discharge current. Short-circuit current is not an operating rating and must never be used to size an inverter or continuous load.

Before purchase for inverter use, obtain the current manufacturer specification for the battery’s continuous-discharge and surge limits. Then confirm that the BMS, cable, fuse, isolator and connections suit the intended inverter demand.

BMS and Charging

The built-in battery-management system provides manufacturer-listed over-current, short-circuit and over-temperature protection. Protective electronics do not replace appropriate fusing, cable sizing, mounting or charger configuration.

Use LiFePO4-compatible charging equipment within the listed voltage, current and temperature limits. The stated rated charge current is 50A, with a maximum charge current of 100A. Charging is specified from 0°C to 45°C.

Series and Parallel Connections

The listing states that multiple series and parallel connections are supported but does not specify the permitted number. Confirm the current manufacturer limit before designing a battery bank. Only connect matching batteries when expressly permitted.

Package Contents

• One Giantz 200Ah lithium battery
• User instructions

Compare the MOBI 175Ah battery or larger MOBI 300Ah battery. Browse all LiFePO4 batteries and compatible power inverters.

Frequently Asked Questions

Does the 1,200A specification mean it can continuously supply 1,200A?

No. That is listed as short-circuit current, not continuous operating current. Confirm the actual continuous BMS rating before selecting an inverter.

Can it be charged below 0°C?

The listed charging range begins at 0°C. Do not charge below this unless current manufacturer documentation specifically permits it.
