Trina Solar Vertex N 650W+ Shield Hail-Resistant Bifacial Dual Glass Solar Panel | TSM-NED19RC.20
Trina Solar Vertex N 650W+ Shield Hail-Resistant Bifacial Dual Glass Solar Panel | TSM-NED19RC.20
Couldn't load pickup availability
Trina Solar Vertex N 650W+ Shield Hail-Resistant Bifacial Dual Glass Solar Panel | TSM-NED19RC.20
Boost energy generation for Australian commercial solar installations with the Trina Solar Vertex N 650W+ Shield Hail-Resistant Bifacial Dual Glass high-efficiency n-type i-TOPCon photovoltaic module. Manufacturer model family TSM-NED19RC.20 targets professionally engineered solar rooftops, C&I facilities and appropriate utility-scale installations.
Why specify Trina Vertex N?
- High output 650W+ series; supplied bin and power rating confirmed at quotation.
- High-efficiency n-type i-TOPCon photovoltaic technology; manufacturer family maximum module efficiency 24.1%.
- Manufacturer reports tested resistance to 75 mm hail at a 60° tilt and mechanical load up to +8000/-6000 Pa. Confirm compliance to the exact supplied variant.
- Manufacturer engineering and power warranty information available via the official Australian model resources.
Trina Solar technical specifications
| Model family | TSM-NED19RC.20 |
|---|---|
| Rated power class | 650W+ (exact module bin varies) |
| Cell count | 132 |
| Maximum module efficiency | 24.1% |
| Dimensions | 2382 × 1134 × 30 mm |
| Construction | Shield Hail-Resistant Bifacial Dual Glass |
| Manufacturer cell technology | N-type i-TOPCon |
Ordering, bulk discounts and delivery Australia-wide
Contact StarPower Advance Solar Technology for current Trina Solar wholesale-backed project supply, multi-panel quantities and shipping across Australia. See our Trina Solar panel catalogue and bifacial solar panels for compatible technology comparisons.
System suitability
Professional installation, Australian compliance, inverter/MPPT compatibility and mounting calculations are essential. Check the exact supplied power-bin Voc, Isc, Vmp, Imp, weight and electrical ratings in the manufacturer datasheet before ordering. Not designed for direct connection to 12V batteries.
Manufacturer reference: TSM-NED19RC.20 product specifications
Choosing the 650W Trina Solar panel
Vertex N Shield range emphasises improved resistance to hail impacts; hail-resistant is not hail-proof. For accurate system design, refer to the model-specific electrical table and linked Trina Solar datasheet below.
- Find the right fit: Review large-panel dimensions, transport access, frame/mounting compatibility and inverter string design.
- Understand the technology: Bifacial performance depends on useful light reaching the rear; do not assume a fixed rear-side energy gain.
- Australian ordering: Buy online from StarPower Advance Solar Technology with free Australia-wide delivery.
Questions before you order
Does hail resistance mean this panel cannot be damaged?
No. The Shield design improves resilience in the manufacturer's specified tests; extreme events can still cause damage. Check the exact datasheet and mounting requirements.
Is this panel suitable for a caravan or small 12V setup?
This is a large-format PV module, generally intended for properly engineered mounting and compatible inverter or MPPT equipment. Check physical dimensions, weight and local installation requirements before ordering.
Explore other Trina Solar panels to compare wattages and technologies. Check the manufacturer datasheet and delivered panel label before finalising electrical designs.
Trina Solar Vertex N Shield 645W electrical specifications (STC)
Official Australian Trina Solar data for the 645W power bin of TSM-NED19RC.20, at standard test conditions (1000 W/m² irradiance, 25°C cell temperature, AM1.5). These are the manufacturer's 645W-bin figures for this exact Shield model family, not measurements independently certified for a 650W-labelled module.
| Rated power (Pmax) | 645W |
|---|---|
| Maximum power voltage (Vmp) | 41.22V |
| Maximum power current (Imp) | 15.65A |
| Open circuit voltage (Voc) | 49.52V |
| Short circuit current (Isc) | 16.55A |
| Module efficiency | 23.9% |
| Module dimensions | 2382 × 1134 × 30 mm |
| Weight | 39.7 kg |
| Solar cells | 132 n-type i-TOPCon cells |
| Maximum system voltage | 1500V DC |
| Maximum series fuse | 35A |
Power-bin clarification: Trina advertises the Shield family at up to 650W. Its linked Australian electrical datasheet covers 625W–645W bins. The figures above apply to a 645W-labelled Shield module; confirm the exact labelled power bin before shipment and refer to its matching datasheet for system design. Rear-side bifacial gain is installation-dependent and is not included in the 645W front-side STC rating.
Official Trina Shield model information · Manufacturer Australian Shield datasheet (625W–645W).
